Old May 31st, 2018, 15:35   #1
D-cappz
Veteran Member

Join Date: Jul 2013
Location: Victoria
Default KermaTD vs Malone Tuning w/ BorgWarner Series 7 Tubro

KermaTDI, Malone Tuning & BorgWarner Series 7 Tubro
I had the opportunity to test out a tune from both Kerma TDI and Malone tuning. The vehicle is a 03 Jetta 1.92L TDI ALH, 5 speed. The main components in this test are; BorgWarner S7 Turbo, DLC764 nozzles, 11mm IP, stage 2 colt cam, port and polished head, over sized valves, dual valve springs, decat (stock downpipe),2.5” exhaust, PD150 intake manifold and more, but the more shouldn’t matter while comparing these two tuners. This engine has a fresh rebuild with around 3k km on it.
Back in June 2016 before the full rebuild, I was running the 160HP kit from KermaTDI with the BorgWarner S7, stock intercooler and intake manifold. I put my TDI on a Dynocom trailer Dyno at Supreme Diesel’s Dyno days. Max power was 181whp @3300rpms & 324.2ft-lbs @ 2400rpms roughly. Now this was thought to be a little high. So, after a full rebuild I put it to the test on different Dynos with the BorgWarners series 7 turbo.
Supreme Diesel Dyno Days Video: https://youtu.be/yzrzOYfGS1A

On Sep. 29, 2017 made my way over to Vancouver BC to visit the friendly crew at Malone tuning. We got the TDI set up on a Dynapack Hub dyno, did some runs and got some numbers. I was having some injection quantity issues while on the Dyno at Malone tuning, it was set around 1.6mg even though we tried to set it around 3.5mg. I also found later that my lift pump relay was having some ground issues which was causing some fueling issues, but it never stalled while testing. Due to the IQ being set so low it would roll a bit of coal, this was later simmered down by finally getting the IQ set correctly and fixing the lift pump relay problem.
Malone Tuning video: https://www.youtube.com/watch?v=kCdbAtp1tYsn
Dyno charts from Malone
KermaTDI Tune: https://i.gyazo.com/7ecaa7f14826c79f...9b00800b46.png
My Kerma tune vs vnt17, pp520, 11mm pump, otherwise stock TDI
https://i.gyazo.com/53ff873987e88038...74931410dd.png
KermaTDI vs Malone tune: https://i.gyazo.com/6477d4ab565e9e56...c2f5d1367f.png
KermaTDI vs Malone aggressive Tune: https://i.gyazo.com/2438a906badf8f77...1b86429178.png

On Feb. 22, 2018 the Jetta made it onto the Superflow AWD Autodyn 30 dyno at Paradigm Auto Works. With the injection quantity set correctly but the lift pump relay was still acting up causing fueling issues, I hadn’t been able to source the issue quite yet. The TDI did run much better with less smoke with the IQ set around 4.2mg. The numbers on this dyno were very similar to the numbers on the Malone hub dyno, but this is right to the wheels like it would be on the road.
Paradigm dyno video: https://www.youtube.com/watch?v=hQA365sZVu8&t=22s
Paradigm dyno charts: https://datazap.me/u/d-cappz

The TDI ran nicely on both tunes but there were some differences. The noticeable differences right way while driving is Malone’s tune has a smoother throttle response, what I mean by this is 10% throttle felt like 10%, 50% felt like 50% and so on to 100% throttle, it’s very nice while shifting making it a very smooth ride. KermaTDI’s tune is a bit touchy or instant torque, making it kind of a jerky ride, 10% throttle is like 30% and 60% and up feels like 100%, so it’s not as smooth. Right away I noticed that Malones tune did not have as much “passing power” though. At higher RPMs it doesn’t feel like it has as much compared to KermaTDIs tune, it also did not feel like the take off power was as strong, this was also proven when a Dyno was done. Malones suggested tune was 35+ Ft-lbs less than KermaTDIs tune and around 10+ HP less. Malone’s tune did not spool as fast and did offer quite the low-end torque that Kerma does. Malone’s tune would also drop boost quite quickly in the higher RPMs vs the Kerma Tune. Malones tune had a little less smoke and around 200°F lower EGTs along with the smooth throttle response. Malone could match the power with an aggressive tune, but it still didn’t quite feel like Kerma’s tune on the road and it didn’t spool the turbo as fast.

Now the biggest test done was to see how far this BorgWarner S7 could go. With the testing I’ve done and the charts collected, I’ve found that the max HP for this turbo is around the 160-170whp. I’ve now had this turbo in for over 2 years with no issues. It’s been a great turbo and it has taken some high EGTs, with temps reaching upwards of 2000° F with ceramic coated head and pistons and upwards of 1500° F without coating. I am not easy on my car at all and this turbo has held up to everything I’ve given it. I’m full throttle and higher RPMs around 70% of the time, I can’t contain myself.

Iv been very happy with the results of the BorgWarner series 7 turbo. The torque this turbo offers with the KermaTDI tune is great. Keeps the Fuel economy better than I was getting with a VNT15 and gives me just over 2x the power to the wheels. Kerma offers a right up in your face tune with torque and spool so low in the RPMs, which I really enjoy, it does make it for a very responsive/touchy feeling. Malone’s tune does offer a little lower EGTs and a smoother throttle, but with a sacrifice of that fast spool and full torque around 2000rpms. Both companies have had great customer service, have been friendly and offer a lot of great information. Unfortunately, I haven’t had the chance to test these long enough to find who offers the better fuel mileage between the Tuners. But I know I get around 5.6L/100km (42mpg or 50impg) with the KermaTDI tune. Like I said, I’m not easy on the throttle and I live in BC where it is very mountainous and curvy, you won’t see many highways that have a strait stretch for more than a 1km or reach speeds over 80km/h.
Thanks for reading and if you have any questions, don’t hesitate to ask.

Up next is the AWD/4motion dyno’s

You will find charts in pics and S7 vs VNT17 on an ALH.

pic #1: on the hub Dyno @ Malone Tuning


pic #2: Engine bay


pic #3: on Dyno @ Paradigm auto works


pic #4: Kerma tune 00001 WHP


pic #5: Kerma tune 00001 WTQ


pic #6: Malone tune WHP


pic #7: Malone tune WTQ


pic #8: Kerma tune 00002 WHP


pic #9: Kerma tune 00002 WTQ


pic #10: Kerma tune on S7 vs Malone tune on VNT17


more pics, charts and graphs below.
__________________
Upgrades:
ProSport Evo Gauges, Kerma Tune, S7 Turbo, DLC 764, 11mm FIP, 2.5" Exhaust CAT Delete, Ported head, OS Valves, Colt Cam Stg2, Kerma “OMI”, PD150 IM, Kerma FMIC, Darkside EGR/Cooler Delete, Kerma CCV, MANN ProVent, SBC Stage II Endurance, SM FlyWheel, Wavetrac LSD, Sigma 5 Speed SS, R32 LCA Bushings, Zimmerman X Drilled

Last edited by D-cappz; October 28th, 2018 at 14:18.
D-cappz is offline   Reply With Quote
Old May 31st, 2018, 15:37   #2
D-cappz
Veteran Member

Join Date: Jul 2013
Location: Victoria
Default

pic #11: Kerma tune vs Malone tune S7


pic #12: Kerma tune vs Malone aggressive tune S7


pic #13: Kerma tune 00001


pic #14: Kerma tune 00002


pic #15: Malone tune


Kerma Boost logs


http://log.malonetuning.com/chart/23...fCjwAAAA%3D%3D



and here she is =D
__________________
Upgrades:
ProSport Evo Gauges, Kerma Tune, S7 Turbo, DLC 764, 11mm FIP, 2.5" Exhaust CAT Delete, Ported head, OS Valves, Colt Cam Stg2, Kerma “OMI”, PD150 IM, Kerma FMIC, Darkside EGR/Cooler Delete, Kerma CCV, MANN ProVent, SBC Stage II Endurance, SM FlyWheel, Wavetrac LSD, Sigma 5 Speed SS, R32 LCA Bushings, Zimmerman X Drilled

Last edited by D-cappz; October 28th, 2018 at 14:15.
D-cappz is offline   Reply With Quote
Old October 28th, 2018, 09:50   #3
D-cappz
Veteran Member

Join Date: Jul 2013
Location: Victoria
Default

You can follow my 4motion Haldex build here.
http://www.instagram.com/mk4mo_tdi





__________________
Upgrades:
ProSport Evo Gauges, Kerma Tune, S7 Turbo, DLC 764, 11mm FIP, 2.5" Exhaust CAT Delete, Ported head, OS Valves, Colt Cam Stg2, Kerma “OMI”, PD150 IM, Kerma FMIC, Darkside EGR/Cooler Delete, Kerma CCV, MANN ProVent, SBC Stage II Endurance, SM FlyWheel, Wavetrac LSD, Sigma 5 Speed SS, R32 LCA Bushings, Zimmerman X Drilled

Last edited by D-cappz; October 28th, 2018 at 14:18.
D-cappz is offline   Reply With Quote
Old October 29th, 2018, 20:23   #4
Matt-98AHU
Loose Nut Behind the Wheel Vendor

Matt-98AHU's Avatar

Join Date: Apr 2006
Location: Vallejo, CA
Default

Hell yeah Damian.

The AWD build is pretty epic, bud.
__________________
Sole Proprietor, Diesel Autowerks in San Anselmo, CA. One man operation, email is preferred method of contact: email me with inquiries for service.
Matt-98AHU is offline   Reply With Quote
Old November 7th, 2018, 14:51   #5
dunerking
Veteran Member

dunerking's Avatar

Join Date: Oct 2009
Location: Saugus,Ca
TDI(s): 04 Jetta TDI
Default

Nice write up! I also went with the S7 turbo with Kerma tune and have been very happy with my performance and economy! I was a little unsure about going with the S7 turbo as most people seem to lean forwards the VNT 17. So far I'm very pleased,I'm hoping that this setup takes care of me for many years/miles!
__________________
05 Dodge 3500 CTD,2.5 Carli suspension
13 Porsche Cayenne diesel
12 JSW OEM fog lights(sold back to VW)
04 Jetta-5 speed
dunerking is offline   Reply With Quote
Old November 12th, 2018, 00:23   #6
JettaTDIBlack
Veteran Member

Join Date: Jul 2016
Location: Brandon, FL
Fuel Economy: 38.88mpg/City Not tested, yet/Highway
Default

And here I am with a P0730 code earlier tonight just wanting the stock car I recently bought to work. Nice job OP!
JettaTDIBlack is online now   Reply With Quote
Old November 21st, 2018, 10:03   #7
Votblindub
Veteran Member

Votblindub's Avatar

Join Date: Dec 2010
Location: NY
Default

I'm looking at it and thinking to myself "wow, why is this so familiar?", then it hits me that it's Damian's car.
Looking good buddy!
