Old April 15th, 2015, 18:51   #61
waltzconmigo
Veteran Member

Join Date: Nov 2010
Location: chicagoland
TDI(s): none
Default

atlast---thank you for looking into the oil pan possibility, with that (probably out of the way) we are left with the wrong amounts in certain manuals (which ones?) and/or an incorrectly sized dipstick. hopefully, Bigworm will eventually chime back in with any information his cousin was able to gather.
__________________
ciao,
waltz

Last edited by waltzconmigo; April 15th, 2015 at 18:57. Reason: spelling
waltzconmigo is offline   Reply With Quote
Old April 17th, 2015, 07:48   #62
dbias
Veteran Member

Join Date: Jan 2015
Location: Huntington WV
Default







I didn't see this as an oil burning thread at all. Found my oil at the top of the little ball at the end of the dipstick upon arriving home just after purchase.
So I added a liter of the oil I bought before leaving the dealership and it brought it up to the 3/4 area of the dipstick.
Do I feel better now? No. Was the oil right and dipstick a little short?
Was the dipstick right and the oil low?
Since filling it is it right now or have I overfilled it?
When doing an oil change do I follow my manual and put "about 4.5" in?
dbias is offline   Reply With Quote
Old April 17th, 2015, 09:14   #63
tdiatlast
Veteran Member

Join Date: Jan 2009
Location: Fort Worth, Texas
Default

These are the questions for VWoA, NOT members here. No one has the answers except the guys that understand which engine is in the Passat, not the folks that printed the owner's manual
__________________
2014 Passat TDI, 2009 JSW TDI DSG (buyback)
2015 Nissan LeafS ($.02/mile fuel cost)
2014 Toyota Avalon Hybrid Limited (39.5mpg C/H)
2013 Ford CMax Hybrid (39.2mpg C/H)
2014 Cadillac ELR, purchased 3/18
tdiatlast is offline   Reply With Quote
Old April 17th, 2015, 13:51   #64
armstrongtrucks
Veteran Member

armstrongtrucks's Avatar

Join Date: Aug 2005
Location: Butler,PA
Default

Quote:
Originally Posted by dbias View Post



I didn't see this as an oil burning thread at all. Found my oil at the top of the little ball at the end of the dipstick upon arriving home just after purchase.
So I added a liter of the oil I bought before leaving the dealership and it brought it up to the 3/4 area of the dipstick.
Do I feel better now? No. Was the oil right and dipstick a little short?
Was the dipstick right and the oil low?
Since filling it is it right now or have I overfilled it?
When doing an oil change do I follow my manual and put "about 4.5" in?
On my oil change with on my 2015 the right dipstick with 4.5 quarts level is at bottom line on letter C. This is why I started this post.
__________________
2015 PASSAT TDI SEL PREMIUM
armstrongtrucks is offline   Reply With Quote
Old April 18th, 2015, 07:54   #65
dbias
Veteran Member

Join Date: Jan 2015
Location: Huntington WV
Default

After 4k miles in first 35 days if ownership this is the oil level. Exact same spot it was after adding a liter of oil upon arriving home from the dealership.


Thing is my dipstick doesn't look like either of the examples in the book. The black gap at top of the hash marks makes no sense to me. How could you tell where the oil is on a black surface.

Last edited by dbias; April 18th, 2015 at 07:58.
dbias is offline   Reply With Quote
Old April 18th, 2015, 12:53   #66
tdiatlast
Veteran Member

Join Date: Jan 2009
Location: Fort Worth, Texas
Default

If you're new to VW diesels, you're learning about the awkwardness of reading the dipstick.

A proven method is to remove the dipstick, wipe it completely dry, reinsert, remove it slowly, and lay it on a clean paper towel. Roll the dipstick and observe the oil stain on the paper.
__________________
2014 Passat TDI, 2009 JSW TDI DSG (buyback)
2015 Nissan LeafS ($.02/mile fuel cost)
2014 Toyota Avalon Hybrid Limited (39.5mpg C/H)
2013 Ford CMax Hybrid (39.2mpg C/H)
2014 Cadillac ELR, purchased 3/18
tdiatlast is offline   Reply With Quote
Old May 1st, 2015, 14:00   #67
eats1963
Veteran Member

eats1963's Avatar

Join Date: May 2007
Location: Saint Anne, IL
Default

So, when the dealer did my oil change, I needed to extract 1/2 quart to get the level down into the cross hatched area of the dipstick. When I called them and complained, they sent me the following and said that they are following the capacities that VWOA is telling them to use.



So, I told them that my owners manual tells me to use about 4.5 qts. They didn't have an answer for me on that. So, the difference between the owners manual, and the capacity chart is 1.3 qts. Which one should I believe???
__________________
2015 Passat TDI SEL Premium

Last edited by eats1963; May 1st, 2015 at 14:02.
eats1963 is offline   Reply With Quote
Old May 1st, 2015, 17:28   #68
Matt927
Veteran Member

Matt927's Avatar

Join Date: Dec 2013
Location: Northeast
TDI(s): several
Default

Not a Passat, but just took delivery of a 2015 Golf TDI. Owners manual states capacity at 5.5 liters. Oil level was to the full mark at delivery.

Last edited by Matt927; May 1st, 2015 at 17:33.
Matt927 is offline   Reply With Quote
Old May 1st, 2015, 17:30   #69
tdiatlast
Veteran Member

Join Date: Jan 2009
Location: Fort Worth, Texas
Default

^^^same engine...same sump capacity...5.5 liters/5.8 quarts
__________________
2014 Passat TDI, 2009 JSW TDI DSG (buyback)
2015 Nissan LeafS ($.02/mile fuel cost)
2014 Toyota Avalon Hybrid Limited (39.5mpg C/H)
2013 Ford CMax Hybrid (39.2mpg C/H)
2014 Cadillac ELR, purchased 3/18
tdiatlast is offline   Reply With Quote
Old May 7th, 2015, 14:00   #70
Rumblesis
Newbie

Join Date: May 2012
Location: Atlanta, GA
Default

My check engine light came on at 980 miles, and when I did a Car-Net check, it said I had too much oil in my car! Took it to dealer, and sure enough, he said several new 2015's were coming in with that error code. Be careful!
Rumblesis is offline   Reply With Quote
Old May 7th, 2015, 15:36   #71
TurboDieselPoint
Veteran Member

Join Date: May 2012
Location: N/A
Default

Quote:
Originally Posted by eats1963 View Post
So, when the dealer did my oil change, I needed to extract 1/2 quart to get the level down into the cross hatched area of the dipstick. When I called them and complained, they sent me the following and said that they are following the capacities that VWOA is telling them to use.



So, I told them that my owners manual tells me to use about 4.5 qts. They didn't have an answer for me on that. So, the difference between the owners manual, and the capacity chart is 1.3 qts. Which one should I believe???
That chart calls for 5.5L. Oil comes in 1L bottles. I'll bet they poured in all 6 bottles and didn't bother stopping at 5.5L. They figure most owners never check their oil so its better to have too much oil than too little, and don't want to deal with having a 1/2L left over from every oil change.

This would indicate that the true oil capacity of the engine is indeed 5.5L and would explain the roughly 1/2 quart over fill.
TurboDieselPoint is offline   Reply With Quote
Old May 7th, 2015, 15:51   #72
eats1963
Veteran Member

eats1963's Avatar

Join Date: May 2007
Location: Saint Anne, IL
Default

Quote:
Originally Posted by TurboDieselPoint View Post
That chart calls for 5.5L. Oil comes in 1L bottles. I'll bet they poured in all 6 bottles and didn't bother stopping at 5.5L. They figure most owners never check their oil so its better to have too much oil than too little, and don't want to deal with having a 1/2L left over from every oil change.

This would indicate that the true oil capacity of the engine is indeed 5.5L and would explain the roughly 1/2 quart over fill.
The quantity on my invoice stated 5 units. Not sure if that meant 5 quarts, or 5 litres?
__________________
2015 Passat TDI SEL Premium
eats1963 is offline   Reply With Quote
Old May 7th, 2015, 16:14   #73
TurboDieselPoint
Veteran Member

Join Date: May 2012
Location: N/A
Default

Quote:
Originally Posted by eats1963 View Post
The quantity on my invoice stated 5 units. Not sure if that meant 5 quarts, or 5 litres?
I would think that means 5 bottles. 507.00 oil comes in 1L bottles, so that would be 5L in theory.

Using only 5L of oil contradicts the chart they gave you, which they used to justify putting in whatever amount of oil they put in. I'm having trouble believing they decided to put only 5L when the chart they gave you to show how much oil they decided to put in showed 5.5L.

Perhaps the service writer billed VW for only 5 bottles instead of 6 bottles out of habit or ignorance since all previous CR TDIs took 4.3L of oil, when in reality the tech who had the updated chart used 6 bottles. The only way to figure out how much oil was poured in is to ask the tech who did your oil change.

Just speculating. This mess is a bit confusing. I wasn't there, but I do suspect the oil capacity for the CVCA is indeed 5.5L.

Last edited by TurboDieselPoint; May 7th, 2015 at 16:17.
TurboDieselPoint is offline   Reply With Quote
Old May 8th, 2015, 05:23   #74
armstrongtrucks
Veteran Member

armstrongtrucks's Avatar

Join Date: Aug 2005
Location: Butler,PA
Default

Shame I have never heard anymore from VWoA on this oil level problem.

The oil I purchased is in qt bottles, not liters.

I am still running 4.5 quart in my Passat. I have printed all the e-mail VWoA has sent me hoping it does not hurt anything.
__________________
2015 PASSAT TDI SEL PREMIUM
armstrongtrucks is offline   Reply With Quote
Old May 8th, 2015, 10:33   #75
JDSnead
Newbie
Default

I bought a new 2015 Passat TDI 6M yesterday.

Build date 12/2014.

My owner's manual shows oil capacity of 5.8 q.
__________________


JDSnead is offline   Reply With Quote
